Here you can find a list of devices that can be used with AgroVision sows Mobile. The devices are grouped based on type and purpose.



All-in-one


ProviderDevice name and modelEartag typeSettings in DeviceSettings in the mobileSettings in AgroVision Mobile Sows
MBDCHHC 9000

LF or UHFNo settings. Setting done by providerNo settings. Setting done by provider1: Open setting
2: Select "Use Bluetooth device".
3: Select "All-in-one"
Coppernic/MBDCC-One (2)LFNo settings. Setting done by providerNo settings. Setting done by provider1: Open setting
2: Select "Use Bluetooth device".
3: Select "All-in-one"


Bluetooth/stickreader




ProviderDevice name and modelEartag typeSettings in DeviceSettings in the mobile
Settings in AgroVision Mobile Sows
Allflex/AgridentAllflex LPRLFNo settings 1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device and start search on your mobile.
3: When the mobile finds a device LPR_#####, then click on it and select "Connect".
 4: The device might need a passkey. This is normally 0000 or 9999.
1: Open setting
2: Select "Use Bluetooth device".
3: Select "RFID scanner"
4: Find you reader LPR_##### from the list shown on screen.

Allflex/AgridentAgrident AWR250LFMenu
• Setup
• Reader Settings
• Set online mode
• Set output format to [ ASCII + SCP]

• Setup
• Interface setup
• Bluetooth
       • Set Bluetooth Mode to [Slave Mode]		1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device and start search on your mobile.
3: When the mobile finds a device AW250_####### , then click on it and select "Connect".
 4: The device might need a passkey. This is normally 0000 or 9999.		1: Open setting
2: Select "Use Bluetooth device".
3: Select "RFID scanner"
4: Find you reader AWR250_####### from the list shown on screen.

Allflex/AgridentAgrident AWR300LFMenu
• Setup
• Reader Settings
• Set online mode
• Set output format to [ ASCII + SCP]

• Setup
• Interface setup
• Bluetooth
       • Set Bluetooth Mode to [Slave Mode]		1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device and start search on your mobile.
3: When the mobile finds a device AWR300_######, then click on it and select "Connect".
 4: The device might need a passkey. This is normally 0000 or 9999.		1: Open setting
2: Select "Use Bluetooth device".
3: Select "RFID scanner"
4: Find you reader AWR300_####### from the list shown on screen.

Allflex/Destron Allflex  RS420LFTo enter setup, hold black button for over three seconds.
Green button, click to move to next line.
Black button, click to select
• Menu "Bluetooth"
• On/Off set to "On"
• Select Device set to "Slave"

• Menu "Reader settings"
• Tag storage mode set to "no storage"

• Menu "General settings"
   • Protocol set to "Standard protocol"		1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device and start search on your mobile.
3: When the mobile finds a device RS420_######, then click on it and select "Connect".
 4: The device might need a passkey. This is normally 1234 or 0000.		1: Open setting
2: Select "Use Bluetooth device".
3: Select "RFID scanner"
4: Find you reader RS420_##### from the list shown on screen.

Datamars Tru-Test XRP2iLF1: Open "Settings"
2: Select "Tag Reading"
3: Select "Tag Format"
4: In "Tag Format" select [Decimal2]		1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device and start search on your mobile.
3: When the mobile finds a device XRS####, then click on it and select "Connect".
 4: The device might need a passkey. This is normally 0000 or 9999.		1: Open setting
2: Select "Use Bluetooth device".
3: Select "RFID scanner"
4: Find you reader XRS#### from the list shown on screen.

TSLTSLUHFNo settings 1: Open Bluetooth on your mobile.
2: Turn on the Bluetooth on your device by clicking the trigger and start the search on your mobile.
3: When the mobile finds a device ######-EU-1128, then click on it and select "Connect".		1: Open setting
2: Select "Use Bluetooth device".
3: Select "TSL reader"
4: Find you reader ######-EU-1128 from the list shown on screen.
